Classic SDR platform, software and hardware are independent and controllable.
HTDMA technology enabling large-scale networking for nodes above 256.
Heterogeneous intelligent channel selection & dynamic adaptive frequency hopping for robust anti-interference.
Supports advanced DES/AES software encryption alongside high-security TF card hardware encryption.
Full backward compatibility with MIMOmesh, SMARTmesh, and ULSC series systems.
Expandable to support PDT/DMR digital intercom systems and cellular 4G/5G routing.
Rugged military-grade built, IP67 dustproof and waterproof with a user-friendly exterior feel.
| System Parameters | |
| Application processor | Octa-core A53 processor with maximum operating frequency of 1.8GHz |
| Operating system | Android 6.0 |
| Screen parameter | 1.8'', TFT LCD (320 X 240) |
| Memory / storage | 2GB RAM + 16GB ROM, 128G Micro SD |
| Voice services | Supports VoIP (PTT) and multi-party conferences |
| Data service | Support file transfer, short message, GIS, IoT data transmission, etc. |
| Video service | Video pull-up, video conferencing, and more are supported |
| Audio, video and data interfaces | 20PIN LEMO IP/USB, 5PIN aviation head words, WiFi IP |
| Main and standby batteries | 7.2~8.4V, 6800mAh |
| Endurance time | ≥ 6h (Transmit: Receive: idle = 1:1:1) |
| Locate the navigation | Built-in GPS/BD |
| Size | 15.5 x 6.6 x 3.2cm (Contains lithium battery, does not include antenna and back clip) |
| Weight | 430g (Contains lithium battery, does not include antenna and back clip) |
| Environmental Parameters | |
| Protection Level | IEC60529-IP67 (1.5m depth for 0.5h) |
| Shock and vibration | MIL-STD-810G compliant |
| Operation Temperature | -40°C ~ +80°C |
| Storage temperature | -55°C ~ +100°C |
| Humidity requirement | 10% ~ 90% (No condensation) |
| Wireless Communication Specs | |
| Communication format | Mobile Ad-hoc NETworking (MANET) ad-hoc network |
| Working frequency |
350-450 / 450-550 / 570-700 / 800-950 MHz, 1000-1200 / 1300-1500 / 1600-1800 / 1800-2000, 1200-1700* MHz, 2.0-2.2 / 2.2-2.5 / 2.5-2.7 / 2.7-2.9, 1.6-2.3 / 1.9-2.7* GHz, 4.4-5.0 / 5.25-5.85, 4.2-5.2 / 5.5-6.0* GHz (70M~6GHz, customized) |
| Transmission system | TDD-COFDM |
| Receive sensitivity | ≤ -103dBm @ 5MHz |
| Transmit power | 1W |
| Carrier bandwidth | 1.25 / 2.5 / 5.0 / 10.0 MHz Settings |
| Transmission capability | 56Mbps @ 10MHz |
| Modulation Mode | BPSK / QPSK / 16QAM / 64QAM / 256QAM (Adaptive) |
| Network scale | Same-frequency networking supports more than 256 nodes |
| Anti-jamming Mode | Inter-frequency intelligent channel selection, full-band dynamic adaptive frequency hopping |
| Encryption | DES56 / AES128 / AES256 Optional |
| Interfaces & Controls | |
| Antenna Interface | SMA x 2 |
| IP Interface | Waterproof navigation plug (reusable with USB interface) |
| USB Interface | Waterproof navigational plug (reusable with IP interface) |
| Headset interface | Contact Wired Headset (PTT) |
| Basic peripheral | Microphone (dual MIC), speaker |
| Front key | Menu button, Home button, confirm button, back button, 4 way button, number button |
| Side key | PTT button, Volume adjustment button, Power button (top), SOS button (top) |
| WiFi AP | 2.4GHz / 5.8GHz, 802.11b/g/h |
This system supports large-scale Mobile Ad-hoc NETworking (MANET) using HTDMA technology. Same-frequency networking can seamlessly scale to support over 256 independent nodes dynamically.
The device features heterogeneous intelligent channel selection and dynamic adaptive frequency hopping across the full frequency band, providing military-grade robustness and strong anti-interference capabilities in complex environments.
The device is engineered for extreme conditions, boasting an IP67 waterproof and dustproof rating (immersion up to 1.5m for 30 minutes). It is compliant with MIL-STD-810G for superior shock and vibration resistance, and operates flawlessly in temperatures ranging from -40°C to +80°C.
Security is fully assured with multiple options, including DES56, AES128, and AES256 software encryptions, alongside dedicated TF card hardware encryption to prevent unauthorized data access.
Equipped with a high-capacity 6800mAh battery, it guarantees ≥6 hours of continuous operation (based on a standard 1:1:1 transmit-receive-idle ratio). It fully supports intensive data operations, including real-time video pull-up, video conferencing, and high-speed data transmission up to 56Mbps @ 10MHz.
